IP Testing
An ISO 17025 Accredited IP Testing Laboratory.
Specialized in IP Testing / Ingress Protection Testing. With Presence across India & Overseas.
Get An Instant Quote
CDG: Premier ISO 17025 Accredited Ingress Protection Testing Laboratory
Welcome to CDG, a leading ISO 17025 accredited testing laboratory specializing in Ingress Protection (IP) Testing. Accredited by ILAC’s accreditation channel, our laboratory is at the forefront of providing comprehensive IP testing services to ensure that your products meet the highest standards for waterproofing, dustproofing, and overall ingress protection. Our accreditation scope encompasses a wide range of IP testing, including IP65, IP67, and IP68 certifications, among others, ensuring your products are rigorously tested for resistance against environmental ingress.
Our Ingress Protection Testing Services
At CDG, we offer a full suite of IP testing services designed to validate the ingress protection levels of your products. Our state-of-the-art IP testing laboratory is equipped to assess the effectiveness of enclosures against intrusion from foreign bodies and moisture, providing you with the assurance that your products can withstand the conditions they’re designed for.
What is Ingress Protection Testing ?
IP (Ingress Protection) Testing is the process of evaluating a product's ability to prevent the ingress of solid objects, dust, and water into its enclosure while maintaining safe and reliable operation. The testing is performed in accordance with IEC 60529, the internationally recognized standard for IP ratings.
An IP Rating consists of two digits: the first digit indicates the level of protection against solid objects and dust, while the second digit indicates the level of protection against water. IP testing helps manufacturers verify product durability, safety, and compliance before products are introduced to the market. It is widely used for electrical equipment, lighting products, consumer electronics, industrial enclosures, automotive components, medical devices, and outdoor equipment.
What is Ingress Protection (IP) Testing?
-
Waterproof Testing
Waterproof Testing evaluates a product's ability to prevent water ingress and continue operating safely when exposed to water. Testing is performed in accordance with IEC 60529, which defines IP (Ingress Protection) ratings to classify the level of protection against water ingress. This testing helps verify product durability, safety, and compliance with international standards.
-
Dustproof Testing
Dustproof Testing evaluates a product's ability to prevent the ingress of dust and other solid particles, ensuring reliable performance in dusty environments. Testing is performed in accordance with IEC 60529, which defines IP (Ingress Protection) ratings for protection against solid objects and dust. This testing helps verify product durability, safety, and compliance with international standards.
Why CDG?
Advanced Ingress Protection Testing for Industry Leaders
CDG’s ingress testing laboratory is equipped with advanced testing equipment and staffed by experienced professionals dedicated to ensuring your products achieve the desired IP certification. Our rigorous testing process, adherence to international standards, and detailed reporting set us apart as a trusted partner for manufacturers across various industries.
Ingress Protection Test Reports and Certification:
Upon completion of testing, CDG provides a detailed Ingress Protection Test Report, outlining the testing protocols, results, and whether the product meets the specified IP standards. Successful products receive IP certification, validating their ingress protection levels and enhancing their marketability.
Tailored IP Testing Across Various Standards
Our laboratory offers tailored testing services across a broad spectrum of IP standards, ensuring comprehensive coverage for all levels of ingress protection:
IP55, IP56 Testing and Certification: For products requiring protection against dust and water jets.
IP57 Tesing and Certification: Assessing products designed for dust protection and temporary immersion.
Custom IP Testing: Beyond standard certifications, we offer customized testing solutions for unique product requirements, ensuring your specific protection needs are met.
What is Ingress Protection (IP)
The IP Code, or Ingress Protection Code is defined in IEC standard 60529 which classifies and rates the degree of protection provided by mechanical casings and electrical enclosures against intrusion, dust, accidental contact, and water. The standard aims to provide users more detailed information than vague marketing terms such as waterproof.
What do the two digits in an IP Rating mean?
An IP (Ingress Protection) Rating consists of two digits that indicate the level of protection provided by an enclosure against solid objects and water.
First Digit (0–6): Indicates the level of protection against solid objects and dust. A higher number represents greater protection, with IP6X being completely dust-tight.
Second Digit (0–9): Indicates the level of protection against water ingress, ranging from dripping water to high-pressure water jets and immersion.
For example, an IP65 rating means the product is completely protected against dust (6) and protected against water jets (5).
First Digit – Protection Against Solid Objects & Dust
0 No protection
1 Objects ≥ 50 mm
2 Objects ≥ 12.5 mm (finger protection)
3 Objects ≥ 2.5 mm (tools, thick wires)
4 Objects ≥ 1.0 mm (small wires, screws)
5 Dust Protected – Limited dust ingress permitted
6 Dust Tight – Complete protection against dust
Second Digit – Protection Against Water
0 No protection
1 Dripping water
2 Dripping water (15° tilt)
3 Spraying water
4 Splashing water
5 Water jets
6 Powerful water jets
7 Temporary immersion (up to 1 m)
8 Continuous immersion (manufacturer-specified conditions)
9 High-pressure, high-temperature water jets
Why Choose CDG for Ingress Protection Testing?
Accredited Expertise
CDG is an ISO/IEC 17025 accredited IP testing laboratory, providing trusted ingress protection testing services with globally recognized technical precision, competence, and reliability.
Comprehensive Testing Services
From dustproof testing to advanced waterproof testing, CDG Inspection offers a complete range of IP testing services, ensuring your products meet stringent protection standards.
Customized Testing Solutions
Understanding that each product has unique challenges, we tailor our testing protocols to meet your specific testing requirements, ensuring effective and accurate certification.
Commitment to Quality
Our primary mission is to help you enhance product reliability and consumer trust by ensuring your products achieve the highest standards of ingress protection.
Contact CDG Today
Embark on your journey toward achieving the highest standards of ingress protection with CDG. Learn more about our IP testing services and discover how we can help your products stand out for their durability and quality. Visit our website, call us, or email us to schedule your ingress protection testing and take the first step towards securing your product’s certification and market success.
An ISO 17020 accredited inspection agency & ISO 17025 accredited testing laboratory
CIL stands as a leading provider in IP testing solutions, offering a comprehensive range of services including ingress protection testing. Our specialized IP testing laboratory, equipped with state-of-the-art facilities, ensures accurate and thorough assessments. We conduct IP testing, waterproof testing, and dustproof testing, covering a wide range of testing such as IP65, IP67, IP68, IP55, IP56, and IP57 etc.
Our adept team is dedicated to providing actionable insights to enhance IP protection, safeguarding your property and personnel. At CIL, we prioritize the safety and well-being of our clients, delivering reliable and efficient IP testing services that exceed expectations. Trust us to ensure the highest standards of IP protection with our expert IP testing solutions.
